AM 5
Active speaker
- 2-Wege Bassreflexsystem
- Alluminium Technologie
- 100 Watt Musikbelastbarkeit
- 14 x 24 x 16 cm (B x H x T)
Item no.: 03420
AM 5 Technical specifications
AM 5
Item no.: 03420
Shipping:
Package
Carton contents:
Canton AM 5
Netzkabel
Gerätefüße
Bedienungsanleitung
weight:
3.1 kg
Packing dimensions:
39 x 24,5 x 23,4 cm
Packing weight:
4,13 kg
Dimensions (WxHxD):
14 x 24 x 16 (5.5'' x 9.4'' x 6.3'') cm
Acoustic principle:
2-way bass reflex system
Principle passive resonator:
bass reflex
Tweeter quantity:
1
Tweeter size:
25 mm
Tweeter material:
Aluminium
Woofer/Midrange driver quantity:
1
Woofer/Midrange driver size:
115
mm
Woofer/Midrange driver material:
aluminium
Nominal power:
100
watts
Transmission range:
50...38.000
Hz
Crossover frequencies:
3.000
Hz
System performance:
80
watts
Standby power consumption ECO/NSB/AUT/MAN:
0,40
watts
Maximum sound pressure:
97 dB SPL
db
Cabinet material:
high-density fiberboard
SNR:
95 dB
db
Common-mode rejection:
yes
Connections:
1 Cinch (RCA)
1 XLR (symmetrical)
Front cover material:
grille
Mounting type front cover:
plugged
Unit feet:
yes
Bass adjustment:
+-6dB
Midrange adjustment:
+-6dB
Tweeter adjustment:
+-6dB
Manual
